Infinity DS-552 merupakan kamera berbentuk dome dan memiliki
infrared dengan jangkauan sampai dengan 20 meter. Kamera ini menggunakan
chipset high-end sony superHAD2 dengan resolusi 540 TVL.Additional Info
- Released On: 2013
- Color Option: White
- Lens Option: 4mm, 6mm (indent)
- Stockable: Non Stockable (Indent Only)
Key Features :
- 540 TVL Sony SuperHAD2
- Day/Night with auto ICR filter cut switch
- Auto white balance, auto gain control, electronic shutter control and backlight compensation
- Internal Synchronization
- Compact design Infinitycctv.com.tw all rightreserved 2013@
- 3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and
- placement
| Model Parameter |
DS-552 |
| 540 TVL Sony SuperHAD2 Dome Camera | |
| Camera | |
| Image Sensor | 1/3" |
| Signal System | PAL/NTSC |
| Effective Pixels | 640 (H) × 480 (V) |
| Min. Illumination | 0.1 Lux @ (F1.2, AGC ON),0 Lux with IR 0.28 Lux @ (F2.0, AGC ON),0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/15,000 s NTSC: 1/30 s to 1/15,000 s |
| Lens | 3.6mm @ F1.8(6mm, 8mm optional) |
| Angle of view: 66.2°(4mm) | |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0 - 355°, Tilt: 0 - 90°, Rotation: 0 - 355° |
| Day & Night | Electronic |
| Horizontal Resolution | 540 TVL |
| Synchronization | Internal synchronization |
| Video Output | 1Vp-p composite output (75 Ω/BNC) |
| S/N Ratio | More than 52 dB |
| General | |
| Operating Conditions | -40 °C - 70 °C (-40 °F - 158 °F) Humidity 90% or less (non-condensing) |
| Power Supply | 12 V DC ± 10% |
| Power Consumption | Max. 1 W(when ICR is switching, Max is 2.5W) |
| Waterproof level | IP66 |
| Dimension (mm) | Φ 89.5×69.8 |
| Weight | 200g |
| IR Distance | 10-20m |
